Specifications
Model |
MZ-77E500B/EU |
MZ-77E1T0B/EU |
MZ-77E2T0B/EU |
Capacity |
500GB |
1TB |
2TB |
Controller |
Samsung MKX |
NAND |
Samsung V-NAND 3bit
MLC |
Form
Factor/Interface |
2.5", 7mm height, SATA3 |
Weight |
45g |
45g |
46g |
DRAM Cache |
512MB LPDDR4 |
1GB LPDDR4 |
2GB LPDDR4 |
Sequential Read |
560 MB/s |
Sequential Write |
530 MB/s |
Random Read 4KB,
QD32 |
98 000 IOPS |
Random Write 4KB,
QD32 |
88 000 IOPS |
Random Read 4KB,
QD1 |
13 000 IOPS |
Random Write 4KB,
QD1 |
36 000 IOPS |
Encryption |
AES
256-bit, TCG/Opal V2.0, IEEE1667 |
TBW |
300 TB |
600 TB |
1200 TB |
Reliability (MTBF) |
1.5 Million Hours
|
Shock (non
operation) |
1500G/0.5ms |
Operating
Temperature |
+0 C... +70 C |
Non Operating Temperatute |
-40 C ...+85 C |
Power Ave/Idle |
2.2W/30mW |
2.5W/30mW |
2.5W/35mW |
Support |
TRIM, Garbage Collection, S.M.A.R.T |
Software |
Magician Software
for SSD management |
Warranty |
Five Years or TBW |
|
